Main Features:

Output Power per Channel: 130W

Impedance at Output Level: 6Ω

Number of Channels: 5

Signal / Noise Ratio: 98 dB

Input Connections:

• 4 x HDMI

• 5 x Composite

• 2 x Component

• 1 x Coaxial

• 2 x Digital Optical

• 1 x USB host

• 1 x iPod/iPhone Digital via USB (cable included)

Output Connections:

• 1 x HDMI

• 1 x Composite

• 1 x Component

Tuner Pre-set Stations: 30

HD Digital Film Direct 24: Yes

MCACC: Yes

HD Audio Formats: Dolby TrueHD, DTS-HD Master Audio

Deep Colour: Yes

x.v.Colour: Yes

HDMI Repeater: Yes

On-Screen Display (GUI): English

Remote Control Glow-key, preset remote control

Power Consumption (in use / standby): 245 W / 0,45 W

Weight: 9,1 kg

Dimensions (W x H x D): 420 x 158 x 348  mm

Surround Sound Formats:

Dolby Digital: Yes

Dolby Digital EX: Yes

Dolby Digital Plus: Yes

Dolby Pro Logic II: Yes

Dolby Pro Logic IIx: Yes

Dolby Pro Logic IIz: Yes

Dolby True HD: Yes

DTS: Yes

DTS-ES: Yes

DTS Neo: Yes

DTS 96/24: Yes

DTS-Express: Yes

DTS-HD High Resolution Audio: Yes

DTS-HD Master Audio: Yes

Surround Modes: 8 + 1 (Action, Drama, Entertainment Show, Advanced Game,

Sports, Classical, Rock/Pop, Unplugged + Extended Stereo)

Power Output:

Power output per channel: 130W

Condition: 1kHz, 1% THD, 6Ω

Rated Power Output: 130W per channel

Input (Sensitivity/Imp.): LINE 200 mV / 45 kΩ

Frequency Response: LINE 5 Hz - 100 kHz +0/-3 dB

Signal-to-Noise Ratio: LINE (DIN) 98 dB

Power Requirements: AC 220 - 230 V / 50/60 Hz

Construction:

Design Discrete Amplification TypeDigital Signal Processor

Texas Instruments Aureus^TM

Amplifier Specifications:

D/A Converter: 192 kHz / 24-bit

A/D Converter: 96 kHz / 24-bit

Input & Output connections:

AV Front Input: Yes

Bluetooth Adapter Port: Yes

Component Video Input/Output: 2/1 (assignable)

Composite Input/Output: 5/1

Digital Optical Input/Output: 2/- (assignable)

Digital Coaxial Input/Output: 1/- (assignable)

HDMI Input/Output: 4/1

Headphone: Yes

Large speaker terminals: Yes

Pre-amp Output: Yes (SW / SB)

Speaker A/B: Yes

USB Host (Front): Yes

iPod Compatibility:

iPod Ready: Yes, via digital direct USB connection (included)

Works with iPhone: Yes

Compatible Generations: 5th Generation, Nano and above, iPhone (including 3G)

Supported Functions: Audio & Video,

(Video with the supplied iPod/iPhone Video + USB Audio cable)

iPhone Control Button: Yes

Audio Features:

Auto Level Control: Yes (2 channel)

Auto Surround: Yes

Dynamic Range Control: Yes

Front Stage Surround Advance: Yes

Midnight Listening Mode: Yes

Phase Control: Yes

Sound Delay: YesAdvanced Sound Retriever: Yes

(2 channel)Stream Direct: Yes

Symmetric EQ: Yes
